Exelia System

Syringe Infusion Pump
- 4.3” reactive colour touchscreen for highintuitivity and quick learning curve.
- Rotary dial for fast and safe programming.
- Pusher anti-bolus brake technology that reducesthe risk of bolus at syringe installation.
- Automatic pressure threshold setting and improved Dynamic Pressure System for fast occlusion detection even at low flow rates.
- Up to 19 custom profiles for personalized device configurations.
- Wide flow rate range from 0.01 to 1200 mL/h and an accuracy of +/- 3 %.

Exelia SP data sheet

Volumetric Infusion Pump
- 4.3” reactive colour touchscreen for high intuitivity and quick learning curve.
- Rotary dial for fast and safe programming.
- Automatic pressure threshold setting and improved Dynamic Pressure System for fast occlusion detection even at low flow rates.
- Up to 20 custom profiles for personalized device configurations.
- Wide flow rate range from 0.1 to 1800 mL/h and an accuracy better than +/- 5 % in most clinical situations.
- > 100 000 data events log.

Exilia VP data sheet

Pump management unit
- Exelia Combox synchronizes drug libraries and device configurations for up to 24 pumps.
- Visible 360° LED to visualize the system status.
- Works with standardized communication protocol, ensuring seamless IT integration.
- Accommodates up to 12 pumps for power centralization.
- Compatible with Exelia SP and VP infusion pumps.
(*) Exelia ComAdaptor is used to exchange data between Exelia Combox and a second column of 12 modules.

Exilia Combox data sheet

Rack System
-Exelia Link is a robust and modular column.
-Up to 3 Exelia Link can be combined to facilitate the organization of up to 12 infusion pumps.
-Two columns can connect a system of up to 24 devices.
-Accommodates up to 12 infusion pumps for power centralization and advanced communication capabilities.
-Compatible with Exelia SP and VP infusion pumps.

Exelia Link data sheet

Pump management unit
- Control up to 24 pumps from the large touchscreen.
- Adjustable height for utmost comfort, even when wearing gloves.
- Centrally program pumps using predefined drug protocols.
- Benefit from the Infusion Relay feature to safely administer catecholamine drugs in the most convenient way.
- Monitor patients closely and graphically via infusion history spanning several days.
- Grasp a global overview of current infusions to optimise workflow oganisation.

Rack system
- Compatible with Exelia Syringe and Volumetric infusion pumps.
- Exelia DuoLink facilitates transportation of up to 2 Exelia SP or VP thanks to the quick pump plugging mechanism.
- Supplies electric power to 2 pumps.
- Quick fastening on a pole or rail.

Exelia DuoLink data sheet
